Zabbix分布式搭建

一.拓扑

所有服务器的硬件指标都是一样的

Centos 7 4核8G内存,需要监控18-19W的监控项

组件说明:

Web server 是前端页面,zabbix有两个选择nginx和apache,默认是apache

Zabbix server是主程序用来管理所有的组件和调度

Zabbix agent 是插件,安装在服务器上可以收集信息反馈给server或者proxy

Zabbix proxy 分担server压力

二.数据库TimesacleDB 10.217.37.146搭建

vim /etc/sysctl.conf

SELINUX=disable

firewall-cmd –state

service firewalld start   #开启

service firewalld restart   #重启

service firewalld stop     #关闭

sudo yum install -y https://download.postgresql.org/pub/repos/yum/11/redhat/rhel-7-x86_64/pgdg-redhat-repo-latest.noarch.rpm

sudo tee /etc/yum.repos.d/timescale_timescaledb.repo <

[timescale_timescaledb]

name=timescale_timescaledb

baseurl=https://packagecloud.io/timescale/timescaledb/el/7/$basearch

repo_gpgcheck=1

gpgcheck=0

enabled=1

gpgkey=https://packagecloud.io/timescale/timescaledb/gpgkey

sslverify=1

sslcacert=/etc/pki/tls/certs/ca-bundle.crt

metadata_expire=300

EOL

sudo yum install -y timescaledb-postgresql-11

/usr/pgsql-11/bin/postgresql-11-setup initdb

systemctl enable postgresql-11 && systemctl start postgresql-11

修改默认用户postgres的密码

su postgres

psql

ALTER USER postgres WITH PASSWORD 'xxxx';

配置数据库监听ip和端口号

vim /var/lib/pgsql/11/data/postgresql.conf

listen_addresses = '*'

port = 5432

允许全部IP可以访问数据库

vim /var/lib/pgsql/11/data/pg_hba.conf

host    all             all             0.0.0.0/0               md5

数据库调优,有个自带的工具timescaledb-tune,自动根据主机性能调整,全部yes就行

su - postgres

timescaledb-tune --pg-config=/usr/pgsql-11/bin/pg_config

systemctl restart postgresql-11

创建数据库zabbix和用户zabbix,对用户增加最高权限和远程访问权限

sudo -u postgres psql

create user zabbix with password 'xxxx';

create database zabbix owner zabbix;

grant all privileges on database zabbix to zabbix;

ALTER ROLE zabbix CREATEROLE SUPERUSER;

查看数据库是否创建成功

playboy=> \l

增加系统用户和密码

sudo adduser zabbix

sudo passwd zabbix

下载源代码把zabbix官网提供的zabbix表进行导入,(因为我服务器下载的慢所以我下载到了我的pc上通过lrzsz 上传到服务器的)

wget https://ayera.dl.sourceforge.net/project/zabbix/ZABBIX%20Latest%20Stable/4.4.4/zabbix-4.4.4.tar.gz

yum install lrzsz –y

tar -xzvf zabbix-4.4.4.tar.gz

cd /usr/local/zabbix-4.4.4/database/postgresql

echo "CREATE EXTENSION IF NOT EXISTS timescaledb CASCADE;" | sudo -u postgres psql zabbix

cat schema.sql | sudo -u postgres psql zabbix

cat images.sql | sudo -u postgres psql zabbix

cat data.sql | sudo -u postgres psql zabbix

cat timescaledb.sql | sudo -u postgres psql zabbix

三.Zabbix Web agent server10.206.230.146搭建

vim /etc/sysctl.conf

SELINUX=disable

firewall-cmd –state

service firewalld start   #开启

service firewalld restart   #重启

service firewalld stop     #关闭

rpm -Uvh

https://repo.zabbix.com/zabbix/4.4/rhel/7/x86_64/zabbix-release-4.4-1.el7.noarch.rpm

yum clean all

yum -y install zabbix-server-pgsql zabbix-web-pgsql zabbix-agent

vim /etc/zabbix/zabbix_server.conf

DBHost=10.217.37.146               #数据库ip

DBName=zabbix    #数据库名称

DBUser=zabbix    #数据库用户名

DBPassword=xxxx    #数据库密码

DBPort=5432     #数据库端口号

预分配子进程数量。数量越多服务端吞吐能力越强,系统资源消耗越大,zabbix server的进程数server端拉取agent端的items

StartPollers=500

系统初始化时,预分配的使用ipmi协议获取主机硬件状态的进程数量。

StartIPMIPollers=10

预处理程序启动数目

StartPreprocessors=3

对不可达主机拉取数据

StartPollersUnreachable=20

陷阱机制,即对于中途加入的主机主动发送的数据进行保存

StartTrappers=15

使用ICMP协议的ping对网络中主机进行在线状态检测

StartPingers=20

对网络中的主机主动扫描发现,对中途加入的主机进行上线。注意:主动发现很消耗带宽

系统初始化时,预分配的自动发现主机的线程数量。若单台代理所管理机器超过500台,可以考虑加大此数值(仅适用于AGENT场景)

StartDiscoverers=50

timers进程的初始数量,它是一个用于处理时间相关的告警进程

StartTimers=10

检查escalations的进程,这张表好像是告警事件表

StartEscalators=10

所有媒介都是并行处理的,当前最大会话每个媒介自己定义,但是zabbix服务的告警处理总数被参数(zabbix_sever.conf)StartAlerters所限制。同一触发器生成的告警会序列化的处理

StartAlerters=3

分配多少共享内存用于存储配置信息,HOST,ITEM,TRIGGER数据,视监控主机数量和监控项调整

CacheSize=4G

Zabbix更新缓存数据的频率,单位为秒

CacheUpdateFrequency=180

数据库同步实例数

将采集数据从CACHE同步到数据库线程数量,视数据库服务器I/O繁忙情况,和数据库写能力调整。数值越大,写能力越强。对数据库服务器I/O压力越大

StartDBSyncers=10

设置划分多少共享内存用于存储采集的历史数据,此数值越大,数据库读压力越小

HistoryCacheSize=512M

历史数据索引缓存

HistoryIndexCacheSize=128M

用于设置划分多少共享内存用于存储计算出来的趋势数据,此参数值从一定程度上可影响数据库读压力

TrendCacheSize=128M

历史数据缓存大小,0为不缓存,

ValueCacheSize=128M

与AGNET、SNMP设备和其它外部设备通信超时设置,单位为秒;若采集数据不完整或网络繁忙,或从管理页面发现客户端状态变化频繁,可以考虑加大此数值。

Timeout=60

定义主机不可达的超时时间

UnreachablePeriod=180

在主机不可用期间,定期检查主机的时间

UnavailableDelay=60

用于服务端数据库慢查询功能,单位是毫秒。若有服务端数据库监控慢查询的需求,可以视具体情况调整此数

LogSlowQueries=3000

启用多少子进程与代理端通信,若代理端较多可考虑加大此数值

StartProxyPollers=1

Zabbix服务端将配置文件数据同步到代理端的频率,仅适用于代理端为被动模式情况

ProxyConfigFrequency=300

Zabbix服务端请求代理端采集的数据的频率,仅适用代理端为被动模式情况

ProxyDataFrequency=1

systemctl start zabbix-server && systemctl enable zabbix-server

systemctl status zabbix-server

vim /etc/httpd/conf.d/zabbix.conf

php_value date.timezone Asia/shanghai

php_value memory_limit 2048M

vim /etc/php.ini

memory_limit = 2048M

启动Zabbix server和agent进程,并为它们设置开机自启:

systemctl restart zabbix-server zabbix-agent httpd

systemctl enable zabbix-server zabbix-agent httpd

四. zabbix proxy 10.217.37.188搭建

vim /etc/sysctl.conf

SELINUX=disable

firewall-cmd –state

service firewalld start   #开启

service firewalld restart   #重启

service firewalld stop     #关闭

wget -i -c http://dev.mysql.com/get/mysql57-community-release-el7-10.noarch.rpm

yum -y install mysql57-community-release-el7-10.noarch.rpm

yum -y install mysql-community-server

systemctl start mysqld.service         #数据库必须初始化,初始化后才有数据库文件生成

systemctl status mysqld.service       # Active: active (running)表示正常

systemctl restart mysqld.service

systemctl enable mysqld.service

mysql有默认密码,到mysql.log下查找

grep "password" /var/log/mysqld.log

用root账号进入 数据默认密码

mysql –u root -p

修改root的密码,xxxx就是密码

ALTER USER 'root'@'localhost' IDENTIFIED BY 'xxxx';

创建数据库名称zabbix和zabbix_proxy ,zabbix和proxy数据库编码设置为utf8

create database zabbix character set utf8 collate utf8_bin;

create database zabbix_proxy character set utf8 collate utf8_bin;

注意:删除数据库命令

drop database zabbix;

查看创建好的数据库

show databases;

创建用户zabbix和密码开并启远程权限,@表示哪些ip可以访问数据库,这里写的是zabbix server的ip

grant all privileges on zabbix_proxy.* to zabbix_proxy@10.206.230.146 identified by 'xxxx';

grant all privileges on zabbix_proxy.* to zabbix_proxy@127.0.0.1 identified by 'xxxx';

grant all privileges on zabbix_proxy.* to zabbix_proxy@10.217.37.188 identified by 'xxxx';

grant all privileges on zabbix_proxy.* to root@localhost identified by 'xxxx';

systemctl restart mysqld

安装下载zabbix-proxy,把数据库表schema.sql.gz导入进zabbix-prxoy数据库

rpm –Uvh https://repo.zabbix.com/zabbix/4.4/rhel/7/x86_64/zabbix-release-4.4-1.el7.noarch.rpm

yum clean all

yum -y install zabbix-proxy-mysql

systemctl restart zabbix-proxy

systemctl enable zabbix-proxy

find –name schema.sql.gz

cd ./usr/share/doc/zabbix-proxy-mysql-4.4.4

zcat schema.sql.gz | mysql -h 127.0.0.1 -u zabbix_proxy -p zabbix_proxy

数据库某些表象存储较大,后期无法进行快速查询,将它分块存储,

Zabbix大表有:history,history_log,history_str,history_text,history_uint,trends,trends_uint

官网:

https://www.zabbix.org/wiki/Docs/howto/mysql_partitioning

数据库分区有几种方式,本文使用的是range方式,

数据库分区管理有两种方式:mysql管理,外部脚本,官网推荐使用外部脚本+事件管理

root查看mysql当前版本是否支持分区,显示YES or ACTIVE就是支持,新版本都支持

SELECT plugin_status FROM information_schema.plugins WHERE plugin_name = 'partition';

root进入zabbix库查看事件计划程序是否启用

SHOW GLOBAL VARIABLES LIKE 'event_scheduler';

SET GLOBAL event_scheduler = ON;    #开启

vim /etc/my.cnf

event_scheduler=ON

查询该数据库表的分区字段的最小时钟,以history_uint表示例,如下

select from_unixtime(min(clock)) from history_uint

创建分区表的脚本

vim partition.sql

DELIMITER $$

CREATE PROCEDURE `partition_create`(SCHEMANAME varchar(64), TABLENAME varchar(64), PARTITIONNAME varchar(64), CLOCK int)

BEGIN

/*

SCHEMANAME = The DB schema in which to make changes

TABLENAME = The table with partitions to potentially delete

PARTITIONNAME = The name of the partition to create

*/

/*

Verify that the partition does not already exist

*/

DECLARE RETROWS INT;

SELECT COUNT(1) INTO RETROWS

FROM information_schema.partitions

WHERE table_schema = SCHEMANAME AND table_name = TABLENAME AND partition_description >= CLOCK;

IF RETROWS = 0 THEN

/*

Print a message indicating that a partition was created.

Create the SQL to create the partition.

Execute the SQL from #2.

*/

SELECT CONCAT( "partition_create(", SCHEMANAME, ",", TABLENAME, ",", PARTITIONNAME, ",", CLOCK, ")" ) AS msg;

SET @sql = CONCAT( 'ALTER TABLE ', SCHEMANAME, '.', TABLENAME, ' ADD PARTITION (PARTITION ', PARTITIONNAME, ' VALUES LESS THAN (', CLOCK, '));' );

PREPARE STMT FROM @sql;

EXECUTE STMT;

DEALLOCATE PREPARE STMT;

END IF;

END$$

DELIMITER ;

DELIMITER $$

CREATE PROCEDURE `partition_drop`(SCHEMANAME VARCHAR(64), TABLENAME VARCHAR(64), DELETE_BELOW_PARTITION_DATE BIGINT)

BEGIN

/*

SCHEMANAME = The DB schema in which to make changes

TABLENAME = The table with partitions to potentially delete

DELETE_BELOW_PARTITION_DATE = Delete any partitions with names that are dates older than this one (yyyy-mm-dd)

*/

DECLARE done INT DEFAULT FALSE;

DECLARE drop_part_name VARCHAR(16);

/*

Get a list of all the partitions that are older than the date

in DELETE_BELOW_PARTITION_DATE.  All partitions are prefixed with

a "p", so use SUBSTRING TO get rid of that character.

*/

DECLARE myCursor CURSOR FOR

SELECT partition_name

FROM information_schema.partitions

WHERE table_schema = SCHEMANAME AND table_name = TABLENAME AND CAST(SUBSTRING(partition_name FROM 2) AS UNSIGNED) < DELETE_BELOW_PARTITION_DATE;

DECLARE CONTINUE HANDLER FOR NOT FOUND SET done = TRUE;

/*

Create the basics for when we need to drop the partition.  Also, create

@drop_partitions to hold a comma-delimited list of all partitions that

should be deleted.

*/

SET @alter_header = CONCAT("ALTER TABLE ", SCHEMANAME, ".", TABLENAME, " DROP PARTITION ");

SET @drop_partitions = "";

/*

Start looping through all the partitions that are too old.

*/

OPEN myCursor;

read_loop: LOOP

FETCH myCursor INTO drop_part_name;

IF done THEN

LEAVE read_loop;

END IF;

SET @drop_partitions = IF(@drop_partitions = "", drop_part_name, CONCAT(@drop_partitions, ",", drop_part_name));

END LOOP;

IF @drop_partitions != "" THEN

/*

Build the SQL to drop all the necessary partitions.

Run the SQL to drop the partitions.

Print out the table partitions that were deleted.

*/

SET @full_sql = CONCAT(@alter_header, @drop_partitions, ";");

PREPARE STMT FROM @full_sql;

EXECUTE STMT;

DEALLOCATE PREPARE STMT;

SELECT CONCAT(SCHEMANAME, ".", TABLENAME) AS `table`, @drop_partitions AS `partitions_deleted`;

ELSE

/*

No partitions are being deleted, so print out "N/A" (Not applicable) to indicate

that no changes were made.

*/

SELECT CONCAT(SCHEMANAME, ".", TABLENAME) AS `table`, "N/A" AS `partitions_deleted`;

END IF;

END$$

DELIMITER ;

DELIMITER $$

CREATE PROCEDURE `partition_maintenance`(SCHEMA_NAME VARCHAR(32), TABLE_NAME VARCHAR(32), KEEP_DATA_DAYS INT, HOURLY_INTERVAL INT, CREATE_NEXT_INTERVALS INT)

BEGIN

DECLARE OLDER_THAN_PARTITION_DATE VARCHAR(16);

DECLARE PARTITION_NAME VARCHAR(16);

ELK+Zabbix+TimesacleDB+Grafana 搭建(上)

DECLARE OLD_PARTITION_NAME VARCHAR(16);

DECLARE LESS_THAN_TIMESTAMP INT;

DECLARE CUR_TIME INT;

CALL partition_verify(SCHEMA_NAME, TABLE_NAME, HOURLY_INTERVAL);

SET CUR_TIME = UNIX_TIMESTAMP(DATE_FORMAT(NOW(), '%Y-%m-%d 00:00:00'));

SET @__interval = 1;

create_loop: LOOP

IF @__interval > CREATE_NEXT_INTERVALS THEN

LEAVE create_loop;

END IF;

SET LESS_THAN_TIMESTAMP = CUR_TIME + (HOURLY_INTERVAL * @__interval * 3600);

SET PARTITION_NAME = FROM_UNIXTIME(CUR_TIME + HOURLY_INTERVAL * (@__interval - 1) * 3600, 'p%Y%m%d%H00');

IF(PARTITION_NAME != OLD_PARTITION_NAME) THEN

CALL partition_create(SCHEMA_NAME, TABLE_NAME, PARTITION_NAME, LESS_THAN_TIMESTAMP);

END IF;

SET @__interval=@__interval+1;

SET OLD_PARTITION_NAME = PARTITION_NAME;

END LOOP;

SET OLDER_THAN_PARTITION_DATE=DATE_FORMAT(DATE_SUB(NOW(), INTERVAL KEEP_DATA_DAYS DAY), '%Y%m%d0000');

CALL partition_drop(SCHEMA_NAME, TABLE_NAME, OLDER_THAN_PARTITION_DATE);

END$$

DELIMITER ;

DELIMITER $$

CREATE PROCEDURE `partition_verify`(SCHEMANAME VARCHAR(64), TABLENAME VARCHAR(64), HOURLYINTERVAL INT(11))

BEGIN

DECLARE PARTITION_NAME VARCHAR(16);

DECLARE RETROWS INT(11);

DECLARE FUTURE_TIMESTAMP TIMESTAMP;

/*

* Check if any partitions exist for the given SCHEMANAME.TABLENAME.

*/

SELECT COUNT(1) INTO RETROWS

FROM information_schema.partitions

WHERE table_schema = SCHEMANAME AND table_name = TABLENAME AND partition_name IS NULL;

/*

* If partitions do not exist, go ahead and partition the table

*/

IF RETROWS = 1 THEN

/*

* Take the current date at 00:00:00 and add HOURLYINTERVAL to it.  This is the timestamp below which we will store values.

* We begin partitioning based on the beginning of a day.  This is because we don't want to generate a random partition

* that won't necessarily fall in line with the desired partition naming (ie: if the hour interval is 24 hours, we could

* end up creating a partition now named "p201403270600" when all other partitions will be like "p201403280000").

*/

SET FUTURE_TIMESTAMP = TIMESTAMPADD(HOUR, HOURLYINTERVAL, CONCAT(CURDATE(), " ", '00:00:00'));

SET PARTITION_NAME = DATE_FORMAT(CURDATE(), 'p%Y%m%d%H00');

-- Create the partitioning query

SET @__PARTITION_SQL = CONCAT("ALTER TABLE ", SCHEMANAME, ".", TABLENAME, " PARTITION BY RANGE(`clock`)");

SET @__PARTITION_SQL = CONCAT(@__PARTITION_SQL, "(PARTITION ", PARTITION_NAME, " VALUES LESS THAN (", UNIX_TIMESTAMP(FUTURE_TIMESTAMP), "));");

-- Run the partitioning query

PREPARE STMT FROM @__PARTITION_SQL;

EXECUTE STMT;

DEALLOCATE PREPARE STMT;

END IF;

END$$

DELIMITER ;

7是数据保存天数,1小时表示每隔多久生成一个分区,48表示本次一共生成多少个分区

DELIMITER $$

CREATE  PROCEDURE`partition_maintenance_all`(SCHEMA_NAME VARCHAR(32))BEGIN

CALL partition_maintenance(SCHEMA_NAME, 'history', 7, 1, 48);

CALL partition_maintenance(SCHEMA_NAME, 'history_log', 7, 1, 48);

CALL partition_maintenance(SCHEMA_NAME, 'history_str', 7, 1,4 8);

CALL partition_maintenance(SCHEMA_NAME, 'history_text', 7, 1,48);

CALL partition_maintenance(SCHEMA_NAME, 'history_uint', 7, 1, 48);

CALL partition_maintenance(SCHEMA_NAME, 'trends', 7, 1, 48);

CALL partition_maintenance(SCHEMA_NAME, 'trends_uint', 7, 1, 48);END$$

DELIMITER ;

对数据库zabbix导入脚本

mysql -uroot -p zabbix_proxy < partition.sql

添加linux脚本的定时任务,每天夜里1点01分开始执行

cd ./usr/share/doc/zabbix-server-mysql-4.4.3目录下有crontab.txt定时任务

根据实际情况填写

Vim crontab.txt

#zabbix partition_maintenance

01 01 * * * mysql -uroot -p'xxxx' zabbix  -e "CALL partition_maintenance_all('zabbix');"

新创建的定时任务生效,查看定时任务,保证服务器重启后任务可以自动启动

crontab crontab.txt

crontab -l

systemctl start crond.service

systemctl enable crond.service

service crond status

进入zabbix数据库查看是否自动添加了分区表,下面以history_uint为例

show create table history_uint;

查zabbix数据库各个表占用情况

select table_name, (data_length+index_length)/1024/1024 as total_mb, table_rows from information_schema.tables where table_schema='zabbix';

停止mysql

service mysqld stop

进入mysql配置表进行配置修改

vim /etc/my.cnf

[mysqld]下增加如下参数:

innodb 引擎使用独立表项

innodb_file_per_table=1

zabbix在使用数据库的过程中,特别是删除历史数据的过程中,会涉及到大数据操作,如果逻辑日志文件太小,会造成执行不成功,日志回滚的问题

数值参考

show engine innodb status\G;

(Log sequence number减去Last checkpoint at )/1024/1024

距离最好不要超过innodb_log_file_size的0.75.

innodb_log_file_size=20M

InnoDB需要innodb buffer pool中处理缓存,其中包含数据缓存 索引缓存 缓冲数据 内部结构

show global status like 'Innodb_buffer_pool_pages_data';

show global status like 'Innodb_buffer_pool_pages_total';

show global status like 'Innodb_page_size';

计算Innodb_buffer_pool_pages_data/Innodb_buffer_pool_pages_total*100%

当结果 > 95% 则增加 innodb_buffer_pool_size, 建议使用物理内存的 75%

当结果 < 95% 则减少 innodb_buffer_pool_size,

Innodb_buffer_pool_pages_data * Innodb_page_size * 1.05 / (1024*1024*1024)

innodb_buffer_pool_size=6G

关闭符号链接

symbolic-links=0

慢查询日志存储

slow_query_log=/var/log/mysql.slow.log

back_log值指出在MySQL暂时停止回答新请求之前的短时间内多少个请求可以被存在堆栈中。也就是说,如果MySql的连接数达到max_connections时,新来的请求将会被存在堆栈中,以等待某一连接释放资源,该堆栈的数量即back_log,如果等待连接的数量超过back_log,将不被授予连接资源。

back_log=500

数据库连接超时时间

connect_timeout=5

多个表关联的时候 减少参与被驱动表的join操作

join_buffer_size=2M

它决定索引处理的速度,尤其是索引读的速度。

key_reads /key_read_requests应该尽可能的低,至少是1:100,1:1000更好

show global status like 'key_read%';

key_buffer_size=16M

开启慢查询,时间超过1秒就算慢

long_query_time=1

”MySQL: ERROR 1040: Too many connections”的异常情况,造成这种情况的一种原因是访问量过高,MySQL服务器抗不住,这个时候就要考虑增加从服务器分散读压力,另一种原因就是MySQL配置文件中max_connections值过小

show variables like '%max_connections%';

show global status like 'Max_used_connections';

Max_used_connections / max_connections * 100%>10%

max_connections=1000

接受的数据包大小,默认40M

max_allowed_packet=40M

安全参数防止暴力破解密码

max_connect_errors=10

这个参数的意思就是是否开启合并insert,默认是开启的,用白话讲就是用mysqldump导出生成的insert数据合并成一条,如果不开启就是一条数据一个insert.,最大值是16M

net_buffer_length=16M

配置MySql日志何时写入硬盘的参数,

当设置为0,该模式速度最快,但不太安全,mysqld进程的崩溃会导致上一秒钟所有事务数据的丢失。

当设置为1,该模式是最安全的,但也是最慢的一种方式。在mysqld 服务崩溃或者服务器主机crash的情况下,binary log 只有可能丢失最多一个语句或者一个事务。。

当设置为2,该模式速度较快,也比0安全,只有在操作系统崩溃或者系统断电的情况下,上一秒钟所有事务数据才可能丢失。

查找资料时候看到其他文章说innodb_flush_log_at_trx_commit和sync_binlog 两个参数是控制MySQL 磁盘写入策略以及数据安全性的关键参数,当两个参数都设置为1的时候写入性能最差,推荐做法是innodb_flush_log_at_trx_commit=2,sync_binlog=500 或1000

innodb_flush_log_at_trx_commit=2

sync_binlog=1000

推荐参数

max_join_size=4294967295

参数来控制写的优先级,当一个表的读锁达到这个数的时候,MySQL会暂时的,降低写的优先级.MySQL尽量少用一些看似精妙但复杂的语句,因为你复杂可能导致给表加的读锁时间就长,会导致写的操作无法进行. 数值为1就是让读和写交替进行

show status like "innodb_row_lock%";

max_write_lock_count=1

是MySQL读入缓冲区大小。对表进行顺序扫描的请求将分配一个读入缓冲区,MySQL会为它分配一段内存缓冲区。

read_buffer_size=1M

这个变量定义了用户可以创建的内存表(memory table)的大小,但是对于已经存在的内存表就没有什么用了,除非这个表被重新创建(create table)或者修改(alter table)或者truncate table。服务重启也会设置已经存在的内存表为全局max_heap_table_size的值。

这个变量和tmp_table_size一起限制了内部内存表的大小。 暂不关注

max_heap_table_size=256M

tmp_table_size=1048576

max_tmp_tables=32

在排序BLOB或TEXT值时使用的字节数(每个值仅头max_sort_length个字节被使用;其余的被忽略)。

max_sort_length=1024

使用CREATE TABLE或CREATE DATABASE语句指定的大小写字母在硬盘上保存表名和数据库名。名称比较对大小写敏感,默认0

lower_case_table_names=0

insert delayed这个特性,异步插入到数据库,MySQL的这个特性,是MySQL对标准SQL的一个扩展,从MySQL 3.22.15 引入,5.6已经不推荐使用,5.7已经不支持了,虽然能识别,但是已经被忽略掉

delayed_insert_timeout=300

delayed_insert_limit =100

delayed_queue_size=5000

max_delayed_threads=20

为非0值时,MySQL服务器会将所有打开的表每隔flush_time指定的时长进行关闭,默认是0

flush_time=0

interactive_timeout针对交互式连接,wait_timeout针对非交互式连接

通过mysql客户端连接数据库是交互式连接,通过jdbc连接数据库是非交互式连接。

默认都是28800

wait_timeout=28800

interactive_timeout=28800

每个连接线程被创建时,MySQL给它分配的内存大小。当MySQL创建一个新的连接线程时,需要给它分配一定大小的内存堆栈空间,以便存放客户端的请求的Query及自身的各种状态和处理信息推荐使用默认值

show variables like 'thread%';

thread_stack=256K

[mysqld_safe]

log-error=/var/log/mysqld.log

pid-file=/var/run/mysqld/mysqld.pid

systemctl restart mysqld

yum -y install zabbix-agent

systemctl restart zabbix-agent.service

systemctl enable zabbix-agent.service

Zabbix 数据库

版权声明:本文内容由网络用户投稿,版权归原作者所有,本站不拥有其著作权,亦不承担相应法律责任。如果您发现本站中有涉嫌抄袭或描述失实的内容,请联系我们jiasou666@gmail.com 处理,核实后本网站将在24小时内删除侵权内容。

上一篇:以运维和开发的视角纵观Docker
下一篇:python-Tkinter界面组件属性介绍(二)
相关文章
