使用机器人操作系统ROS 2和仿真软件Gazebo 9环境综合测试教程（三）

在完成教程（一）搭建机器人和（二）命令遥控可视化后，将仿真机器人用于更为逼真的环境，可以测试如SLAM，区域覆盖以及场馆巡逻算法，这里环境均采用aws提供模型，分别为smallhouse和bookstore，环境适用于ROS2和ROS1全部案例，但ROS1内容不做讲解，这里只简要叙述一下ROS2中调试和使用的过程。

ROS2和Gazebo9中mobot室内环境仿真测试

在环境中添加机器人模型：

在launch中添加机器人需要注意如上差异，如添加一个urdf格式机器人可参考如下命令：

ros2 service call /spawn_entity 'gazebo_msgs/SpawnEntity' '{name: "urdf_ball", xml: ""}'

更多内容参考：https://github.com/ros-simulation/gazebo_ros_pkgs/wiki/ROS-2-Migration:-Spawn-and-delete

如果需要在制定位置插入机器人，需要查阅spawn_entity.py源码：

# Encode xml object back into string for service call

entity_xml = ElementTree.tostring(xml_parsed)

# Form requested Pose from arguments

initial_pose = Pose()

initial_pose.position.x = float(self.args.x)

initial_pose.position.y = float(self.args.y)

initial_pose.position.z = float(self.args.z)

q = quaternion_from_euler(self.args.R, self.args.P, self.args.Y)

initial_pose.orientation.w = q[0]

initial_pose.orientation.x = q[1]

initial_pose.orientation.y = q[2]

initial_pose.orientation.z = q[3]

注意这里的initial_pose和表中参数的对应情况，不再赘述。

mobot加入smallhouse场景如下所示，支持多机器人！后续补充：

可以在此环境中复习，前2课所学过的全部内容。

启动文件smallhouse.launch.py代码如下：

import os

from ament_index_python.packages import get_package_share_directory

from launch import LaunchDescription

from launch.actions import ExecuteProcess, DeclareLaunchArgument

from launch.actions import IncludeLaunchDescription

from launch_ros.actions import Node

from launch.conditions import IfCondition

from launch.launch_description_sources import PythonLaunchDescriptionSource

from launch.substitutions import LaunchConfiguration

# this is the function launch system will look for

def generate_launch_description():

robot_name = 'mobot'

world_file_name = 'smallhouse.world'

# full path to urdf and world file

world = os.path.join(get_package_share_directory(robot_name), 'worlds', world_file_name)

urdf = os.path.join(get_package_share_directory(robot_name), 'urdf', 'mobot.urdf')

# read urdf contents because to spawn an entity in

# gazebo we need to provide entire urdf as string on command line

#small_house = launch.actions.IncludeLaunchDescription(

# launch.launch_description_sources.PythonLaunchDescriptionSource(

# os.path.join(

# get_package_share_directory('aws_robomaker_small_house_world'),

# 'launch',

# 'small_house.launch.py')))

# Spawn mobot

spawn_mobot = Node(

package='gazebo_ros',

node_executable='spawn_entity.py',

node_name='spawn_entity',

#node_namespace=namespace_,

output='screen',

#emulate_tty=True,

arguments=['-entity',

'mobot',

'-x', '3.5', '-y', '1.0', '-z', '0.1',

'-file', urdf

]

)

#xml = open(urdf, 'r').read()

# double quotes need to be with escape sequence

#xml = xml.replace('"', '\\"')

# this is argument format for spwan_entity service

#spwan_args = '{name: \"mobot\", xml: \"' + xml + '\"}'

# create and return launch description object

return LaunchDescription([

# start gazebo, notice we are using libgazebo_ros_factory.so instead of libgazebo_ros_init.so

# That is because only libgazebo_ros_factory.so contains the service call to /spawn_entity

ExecuteProcess(

cmd=['gazebo', '--verbose', world, '-s', 'libgazebo_ros_factory.so'],

output='screen'),

# tell gazebo to spwan your robot in the world by calling service

# ExecuteProcess(

# cmd=['ros2', 'service', 'call', '/spawn_entity', 'gazebo_msgs/SpawnEntity', spwan_args],

# output='screen'),

#small_house,

spawn_mobot,

])

机器人初始位置为x: 3.5 y: 1.0 z: 0.1，参考如下文档片段：

Robot Simulation - Initial Position

Do not use (0,0,0) for the initial position as it will collide with the lounge chairs. Instead, a resonable position is (3.5,1.0,0.0).

机器人可以加载已有的ROS2功能包，如导航功能包等。

具体参考：2020年ROS机器人操作系统用户官方调查 文末的介绍。

关于环境综合测试更多截图如下所示：

smallhouse：

navigation2:

bookstore:

navigation2:

下一节将讲解如何制作一个跟随机器人～mobot-follow～
