Android 8.1 关机充电动画（二）Uboot模式

system：Android 8.1

platform：RK3326/PX30

uboot

kernel

Android 8.1 关机充电动画（一）模式选择

Android 8.1 关机充电动画（二）Uboot模式

Android 8.1 关机充电动画（三）Android模式

文章目录

前言

相关文档

相关代码

总结

附录

前言

这部分要涉及到uboot下关机充电动画的定制，属于比较low level的部分，所以代码修改的部分不大，在uboot中主要是对多张图片进行轮播，所以这里的主要工作是定位到相应的代码以及如何定制自己的动画。

相关文档

RK在uboot的开发方面已经给出了文档，

其中已经包括了这部分动画如何打包到rom中，不可避免的是需要重新编译uboot，但是图片会被打包到resource.img中。

相关代码

重新回到代码中u-boot/drivers/power/charge_animation.c

struct charge_image { const char *name; int soc; int period; /* ms */ }; /* * IF you want to use your own charge images, please: * * 1. Update the following 'image[]' to point to your own images; * 2. You must set the failed image as last one and soc = -1 !!! */ static const struct charge_image image[] = { { .name = "battery_0.bmp", .soc = 5, .period = 600 }, { .name = "battery_1.bmp", .soc = 20, .period = 600 }, { .name = "battery_2.bmp", .soc = 40, .period = 600 }, { .name = "battery_3.bmp", .soc = 60, .period = 600 }, { .name = "battery_4.bmp", .soc = 80, .period = 600 }, { .name = "battery_5.bmp", .soc = 100, .period = 600 }, { .name = "battery_fail.bmp", .soc = -1, .period = 1000 }, };

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

name ：文件名

soc：图片对应的电量百分比

period：图片显示的时间（单位：ms）

那么，这里问题来了，图片如何打包到固件里呢？

先找到RK提供的打包用的脚本，u-boot/pack_resource.sh

找到需要打包的图片，然后需要修改的直接替换掉，图片采用8bit或24bit bmp格式，图片路径：u-boot/tools/images/，如下图所示：

最终就是如何打包图片了：

cd u-boot && ./pack_resource.sh ../kernel/resource.img

1

执行完以上命令后，终端会输出以下信息，说明打包成功；

Pack ./tools/images/ & resource.img to resource.img ... Unpacking old image(resource.img): rk-kernel.dtb battery_1.bmp battery_2.bmp battery_3.bmp battery_4.bmp battery_5.bmp battery_fail.bmp logo.bmp logo_kernel.bmp battery_0.bmp Pack to resource.img successed! Packed resources: rk-kernel.dtb battery_1.bmp battery_2.bmp battery_3.bmp battery_4.bmp battery_5.bmp battery_fail.bmp logo.bmp logo_kernel.bmp battery_0.bmp resource.img is packed ready

1

2

3

4

5

6

7

并且会在当前的路径下重新生成resource.img，将这个文件重新烧写到设备的对应分区，就可以把充电动画打包到设备的rom中了。

总结

简单介绍了RK平台上进行关机充电uboot模式下充电动画的定制和打包方法，篇幅较短，也可以参考RK官方的文档，下一篇介绍一下，关机充电Android模式下如何进行充电动画的修改。附录是充电动画显示的主要代码。

附录

下面的代码是函数static int charge_animation_show(struct udevice *dev)中的while(1)，这里会一直循环显示充电图片；

/* Charging ! */ while (1) { /* * At the most time, fuel gauge is usually a i2c device, we * should avoid read/write all the time. We had better set * poll seconds to update fuel gauge info. */ if (!first_poll_fg && get_timer(delta) < FUEL_GAUGE_POLL_MS) goto show_images; delta = get_timer(0); debug("step1 (%d)... \n", screen_on); /* * Most fuel gauge is I2C interface, it shouldn't be interrupted * during tansfer. The power key event depends on interrupt, so * so we should disable local irq when update fuel gauge. */ local_irq_disable(); /* Step1: Is charging now ? */ charging = fuel_gauge_get_chrg_online(fg); if (charging <= 0) { printf("Not charging, online=%d. Shutdown...\n", charging); /* wait uart flush before shutdown */ mdelay(5); /* PMIC shutdown */ pmic_shutdown(pmic); printf("Cpu should never reach here, shutdown failed !\n"); continue; } debug("step2 (%d)... show_idx=%d\n", screen_on, show_idx); /* Step2: get soc and voltage */ soc = fuel_gauge_get_soc(fg); if (soc < 0 || soc > 100) { printf("get soc failed: %d\n", soc); continue; } voltage = fuel_gauge_get_voltage(fg); if (voltage < 0) { printf("get voltage failed: %d\n", voltage); continue; } current = fuel_gauge_get_current(fg); if (current == -ENOSYS) { printf("get current failed: %d\n", current); continue; } first_poll_fg = 0; local_irq_enable(); show_images: /* * Just for debug, otherwise there will be nothing output which * is not good to know what happen. */ if (!debug_start) debug_start = get_timer(0); if (get_timer(debug_start) > 20000) { debug_start = get_timer(0); printf("[%8ld]: soc=%d%%, vol=%dmv, c=%dma, online=%d, screen_on=%d\n", get_timer(0)/1000, soc, voltage, current, charging, screen_on); } /* * If ever lowpower screen off, force screen_on=false, which * means key event can't modify screen_on, only voltage higher * then threshold can update screen_on=true; */ if (ever_lowpower_screen_off) screen_on = false; /* * Auto turn on screen when voltage higher than Vol screen on. * 'ever_lowpower_screen_off' means enter while loop with * screen off. */ if ((ever_lowpower_screen_off) && (voltage > pdata->screen_on_voltage)) { ever_lowpower_screen_off = false; screen_on = true; show_idx = IMAGE_SHOW_RESET; } /* * IMAGE_SHOW_RESET means show_idx show be update by start_idx. * When short key pressed event trigged, we will set show_idx * as IMAGE_SHOW_RESET which updates images index from start_idx * that calculate by current soc. */ if (show_idx == IMAGE_SHOW_RESET) { for (i = 0; i < image_num - 2; i++) { /* Find out which image we start to show */ if ((soc >= image[i].soc) && (soc < image[i + 1].soc)) { start_idx = i; break; } if (soc >= 100) { start_idx = image_num - 2; break; } } debug("%s: show_idx=%d, screen_on=%d\n", __func__, show_idx, screen_on); /* Mark start index and start time */ show_idx = start_idx; show_start = get_timer(0); } debug("step3 (%d)... show_idx=%d\n", screen_on, show_idx); /* Step3: show images */ if (screen_on) { /* Don't call 'charge_show_bmp' unless image changed */ if (old_show_idx != show_idx) { old_show_idx = show_idx; debug("SHOW: %s\n", image[show_idx].name); charge_show_bmp(image[show_idx].name); } /* Re calculate timeout to off screen */ if (priv->auto_screen_off_timeout == 0) priv->auto_screen_off_timeout = get_timer(0); } else { priv->auto_screen_off_timeout = 0; system_suspend_enter(pdata); } mdelay(5); /* Every image shows period */ if (get_timer(show_start) > image[show_idx].period) { show_start = get_timer(0); /* Update to next image */ show_idx++; if (show_idx > (image_num - 2)) show_idx = IMAGE_SHOW_RESET; } debug("step4 (%d)... \n", screen_on); /* * Step4: check key event. * * Short key event: turn on/off screen; * Long key event: show logo and boot system or still charging. */ key_state = check_key_press(dev); if (key_state == KEY_PRESS_DOWN) { old_show_idx = IMAGE_SHOW_RESET; /* NULL means show nothing, ie. turn off screen */ if (screen_on) charge_show_bmp(NULL); /* * Clear current image index, and show image * from start_idx */ show_idx = IMAGE_SHOW_RESET; /* * We turn off screen by charge_show_bmp(NULL), so we * should tell while loop to stop show images any more. * * If screen_on=false, means this short key pressed * event turn on the screen and we need show images. * * If screen_on=true, means this short key pressed * event turn off the screen and we never show images. */ if (screen_on) screen_on = false; else screen_on = true; } else if (key_state == KEY_PRESS_LONG_DOWN) { /* Only long pressed while screen off needs screen_on true */ if (!screen_on) screen_on = true; /* Is able to boot now ? */ if (soc < pdata->exit_charge_level) { printf("soc=%d%%, threshold soc=%d%%\n", soc, pdata->exit_charge_level); printf("Low power, unable to boot, charging...\n"); show_idx = image_num - 1; continue; } if (voltage < pdata->exit_charge_voltage) { printf("voltage=%dmv, threshold voltage=%dmv\n", voltage, pdata->exit_charge_voltage); printf("Low power, unable to boot, charging...\n"); show_idx = image_num - 1; continue; } /* Success exit charging */ printf("Exit charge animation...\n"); charge_show_logo(); break; } else { /* Do nothing */ } debug("step5 (%d)... \n", screen_on); /* Step5: Exit by ctrl+c */ if (ctrlc()) { if (voltage >= pdata->screen_on_voltage) charge_show_logo(); printf("Exit charge, due to ctrl+c\n"); break; } }

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230
